Specifications

• Engine

  • Type: V-Twin cylinder, liquid-cooled, SOHC, 8-valves, 4-strokes
  • Displacement: 963 cc
  • Bore and stroke: 91 x 74 mm (3.58 x 2.9 in)
  • Compression: 10.8:1
  • Engine management: Fuel injected engine
  • Cooling system: Liquid
  • Starting: Electric
  • Battery: 30 Ah

• Size / Weight

  • Length x width x height: 2345 x 1264 x 1450 mm (92.3 x 49.7 x 57 in)
  • Wheelbase: 1480 mm (58.3 in)
  • Ground clearance: 300 mm (11.8 in)
  • Minimum turning Radius: 3500 mm (137.7 in)
  • Fuel tank capacity: 26 L (6.8 gal)
  • Curb weight: 460kg (1014 lbs)
  • Towing capacity: 800 kg (1764 lbs)
  • Rack capacity: Front 45 kg (99 lbs) Rear 90 kg (198 lbs)

• Transmission

  • CFMOTO clutch system: variable transmission
  • Gear box: L / H / N / R / P (parking lock shift system)
  • Power train: 2WD / 4WD, electric locking differential

• Wheels

  • Front wheels: Aluminum alloy (14 in)
  • Rear wheels: Aluminum alloy (14 in)
  • Front tires: AT 27 x 9-14
  • Rear tires: AT 27 x 11-14

• Suspension and steering

  • Front suspension: Double A-arm independent, gas shock absorber with adjustable rebound/compression
  • Front travel: 225 mm (8.8 in)
  • Rear suspension: Independent trailing arm, fully adjustable, gas shocks
  • Rear travel: 225 mm (8.8 in)
  • Steering: Electric Power Steering (EPS)
