EZ17 MX TRACK EXCAVATOR
$34,995.00 CAD
listing image
  • listing image
  • listing image
  • listing image
  • listing image
  • listing image
  • listing image
  • listing image
  • listing image
  • listing image
Call 226-216-0887

Item Details

ID: 33586647
Make: Wacker Neuson
Type: New
Year: 2022
Model: EZ17 MX TRACK EXCAVATOR
Options: Array
Main Properties: Array
Technical Specifications: Array

Item Description

8.99% Financing available for 180 months thats only $88.68 a week!
0% Financing available call us for more details
 *Pricing listed is cash price*

Standard Components

- Yanmar 3TNV80F diesel engine, 3-cylinder, liquid cooled, T4F emissions compliant
- 230 mm rubber track
- Dozer blade
- Work light mounted to boom
- Toolkit, including grease press and operator's manual
- Watertight, lockable document box
-Adjustable comfort seat with artificial leather cover and safety belt; canopy (and cabin) complies with current ROPS, TOPS and FOPS* regulations
- *FOPS (level I and II) only with additional protective grating


- LUDV - hydraulic system (load-independent flow distribution)
- Variable displacement pump (39.6 L/min)
- Hydraulic pilot control via joystick operation
- Valve control according to ISO, DIN, SAE, PCSA and EURO
- Auxiliary hydraulic connections for two directions of travel, mounted on shovel arm
- Hydraulic oil cooler
- Two travel speeds
- Hydraulic telescopic travel gear, 39 in to 51 in (990 mm – 1,300 mm), with dozer blade extension


Specifications

Superstructure turning speed 10 1/min
Travel speed 4.8 km/h
Break Out Force Bucket 18.7 kN
Break Out Force Lift Arm 9.1 kN
Length 3,585 mm
Operating weight (min.-max.) 1,724 - 2,083 kg
Digging depth (max.) 2,486 mm
Width 990 mm
Height 2,360 mm
Cylinder 3
Cylinder capacity 1,176 cm3
Inclined position max. 30 °
Tank capacity 22 l
Effective power 13.8 KW
Nominal Engine speed 2,200 1/min
Operating power 13.4 KW
Operating Engine speed 2,200 1/min
Starter battery Voltage 12 V
Battery capacity (nom. value) 44 Ah
Motor type Diesel engine
Manufacturer Yanmar
Engine designation 3TNV76 - XNSV

Operating pressure 240 bar
Flow rate 39 l/min
Flow rate max. 39 l/min
Tank capacity 21 l
Operating pressure slewing gear 150 bar
Hydraulikpump Variable displacement pump

Stock Number :19308
