Item Details

Item Description

Specifications

Performance

Operating weight with forks	21,500 lbs (9,752 kg)
Outside turn radius	14' 9" (4.50 m)
Maximum drawbar pull	19,200 lbs (8,709 kg)
Maximum lifting height	42' (12.8 m)
Reach at maximum height	3' (0.91 m)
Maximum forward reach	25' (7.62 m)
Maximum lift capacity	8,000 lbs (3,629 kg)
Lift capacity at maximum height	6,000 lbs (2,722 kg)
Lift capacity at maximum reach	2,000 lbs (907 kg)



Steering
Power assisted steering

Three steering modes: 2-wheel, 4-wheel coordinated, and 4-wheel crab

Engine

John Deere 4045TF270 (Std.) / Deutz BF4M2012 (Opt.)

4 cylinders turbocharged diesel

Power @ 2,500 rpm

Std. 99 hp (73.8 kW) / Opt. 100 hp (74.6 kW)

Tier II Compliant

Transmission

3 speed Powershift/torque converter

4-wheel drive

Front axle differential lock (std)

Maximum speed

18 mph (29 km/h)

Brakes

Inboard multiple wet disc
