Item Details

ID: 14318135
Make: JCB
Type: New

Year: 2019
Model: 510-42 Telehandler

Maximum Lift Capacity: 10,000 lb 4,537 kg

Maximum Lift Height: 42 ft 12.8 m

Engine Power Options: 74/109 hp 55/81 kW

Item Description

The JCB 510-42 telehandler is designed for maximum productivity. With a maximum capacity of 10,000 lb and no requirement for outriggers, operators are able to efficiently move from one project to the next, to complete more tasks.

The 510-42 is built with the benefit of JCB's 40 years of telehandler manufacturing experience. With a one-piece, fully welded chasis and JCB's U-profile boom that has been proven on more than 200,000 machines, the 510-42 delivers the strength and reliability necessary to complete any work site application.

Features

No outriggers/stabilizers with 10,000 lb capacity
10 degrees of frame sway
Large, comfortable operator station
Single, proportional joystick
Dry lubricant for three-section boom
Four-speed powershift transmission

AN INVESTMENT WITH A HIGH RETURN

The 510-42 features the responsive JCB EcoMax engine for fuel-efficient matching of transmission and hydraulics.

JCB Loadall telehandlers meet Tier 4 Final emissions standards with a sealed-for-life SCR system that requires no separate diesel particulate filter (DPF) or productivity-sapping DPF regeneration. The 510-42 is available with a 109 hp engine or a 74 hp engine that requires no DEF and no aftertreatment.

These telehandlers are equipped with a precise, high-speed double-boom-chain extension system for maximum efficiency and reliability.

JCB telescopic handlers are always a smart financial investment. Not only are JCB telehandlers efficient to own and operate, but JCB's incomparable build quality and legendary productivity means that your JCB telehandler will command a premium resale price when it comes time to upgrade your fleet.

VISIBILITY AND SAFETY

JCB Loadall telehandlers are renowned for excellent visibility. The high boom profile and pivot allow the operator good visibility to the sides of the machine and a cut-out over the hydraulic tank provides clear line-of-sight to the rear.

A reverse alarm is a standard feature on all JCB telehandlers.

Hose burst check valves are standard to prevent collapse in the event of a hose failure

WORKING ENVIRONMENT

Choose an operator environment to suit your climate: fully glazed or canopy. The exterior top door slam latch allows the upper door to be closed from outside.

For fast, precise and intuitive control, JCB telescopic handlers feature a fully-proportional, single-lever joystick.

New instruments and a 3.5-inch color TFT screen form an intuitive, automotive-style cab layout. An adjustable, tilting telescopic steering column is also available.

The 7-speed fan heater creates a comfortable, productive operator environment. Optional air conditioning is ideal for work in hotter climates.

JCB's standard-fit tinted cab glass reflects 30 percent of the sun’s energy, for enhanced operator comfort.

SERVICEABILITY AND DURABILITY

JCB telescopic handlers designed to maximize uptime and productivity and built tough with top-quality components. All hydraulic cylinders, cabs, axles, transmissions and engines are built by JCB, and designed to work in perfect harmony for optimum reliability.

The range of JCB lift-and-place telehandlers, including the 510-42, boast 500-hour extended service intervals and simplified maintenance procedures, with easy access to service points.

All daily checks can be done from ground level, and the battery is accessible via a lockable cover. A battery isolator switch is also standard.

A dry lubricant system means wear pads are extremely durable, with service intervals of 500 hours – compared to approximately 250 hours for competitor machine sin this class.
