Item Details
ID: 13871766
Make: HLA Snow
Type: New
Year: 2018
Model: 5200W Series
Item Description
|
|
|
Features
|
-
2 Year Warranty
-
180° Rotation
-
Crossover Relief Valve
-
Floating End Plate Edge
-
Lateral Float
-
Mouldboard Profile
-
Nitrate Rods on Angle Cylinders
-
Replaceable, Reversible Cutting Edge
-
Rotary Actuators - PATENTED
-
Skid Shoes
-
Spring Trip Cutting Edge
-
Tire Protection System - PATENTED
|
|
Specifications
|
|
|
|
Part # |
Approx. Weight (LBS.) |
Clearing Width Closed (in.) |
Clearing Width Open (in.) |
Overall Road Width (Angled) (in.) |
Snow Clearing Width (Angled) (in.) |
Mouldboard Height |
Max Operating Weight (lbs.) |
|
SB5200W915 |
3,440 |
108 |
180 |
103 |
146 |
42" |
40,000 |
|
SB5200W1016 |
3,605 |
120 |
192 |
113 |
156 |
42" |
40,000 |
|
SB5200W1218 |
3,865 |
144 |
216 |
133 |
176 |
42" |
40,000 |
|
SB5200W1420 |
4,155 |
168 |
240 |
153 |
196 |
42" |
40,000 |
|
SB5200W1622 |
4,475 |
192 |
264 |
173 |
216 |
42" |
40,000 |
|
|
|
