Item Details
ID: 13871709
Make: HLA Snow
Type: New
Year: 2018
Model: 5205W Series
Item Description
|
|
|
Features
|
-
2 Year Warranty
-
Removeable Upper Wing Tip
-
180° Rotation
-
Crossover Relief Valve
-
Floating End Plate Edge
-
Lateral Float
-
Nitrate Rods on Angle Cylinders
-
Replaceable, Reversible Cutting Edge
-
Rotary Actuators - PATENTED
-
Skid Shoes
-
Spring Trip Cutting Edge
-
Tire Protection System - PATENTED
|
|
Specifications
|
|
|
|
Part # |
Approx. Weight (LBS.) |
Clearing Width Closed (in.) |
Clearing Width Open (in.) |
Overall Road Width (Angled) (in.) |
Snow Clearing Width (Angled) (in.) |
Mouldboard Height |
Max Operating Weight (lbs.) |
|
SB5205W919 |
4,115 |
108 |
228 |
103 |
189 |
42" |
40,000 |
|
SB5205W1020 |
4,245 |
120 |
240 |
113 |
199 |
42" |
40,000 |
|
SB5205W1222 |
4,510 |
144 |
264 |
133 |
219 |
42" |
40,000 |
|
SB5205W1424 |
4,800 |
168 |
288 |
153 |
239 |
42" |
40,000 |
|
SB5205W1626 |
5,120 |
192 |
312 |
173 |
259 |
42" |
40,000 |
|
|
|
