Item Details
ID: 13667099
Make: HLA Snow
Type: New
Year: 2016
Model: 4206W Series
Item Description
|
|
|
Features
|
-
2 Year Warranty
-
6' Wings
-
Removeable Upper Wing Tip
-
180° Rotation
-
Crossover Relief Valve
-
Floating End Plate Edge
-
Lateral Float
-
Nitrate Rods on Angle Cylinders
-
Replaceable, Reversible Cutting Edge
-
Rotary Actuators - PATENTED
-
Skid Shoes
-
Spring Trip Cutting Edge
-
Tire Protection System - PATENTED
|
|
Options
|
-
Rubber Cutting Edge
-
Spill Guard
-
Boron or Carbide Cutting Edges
-
High Tensile Long Wear Skid Shoes
-
Curb Runner
-
Floating Blade Hinge
|
|
Part # |
Clearing Width Closed (in.) |
Clearing Width Open (in.) |
Overall Road Width (Angled) (in.) |
Snow Clearing Width (Angled) (in.) |
Mouldboard Height (in.) |
Weight (lbs.) |
Max Operating Weight (lbs.) |
|
SB4206W820 |
93.5 |
237.5 |
91 |
109 |
34 |
3,355 |
25,000 |
|
SB4206W921 |
108 |
252 |
102 |
205 |
34 |
3,505 |
25,000 |
|
SB4206W1022 |
120 |
264 |
112 |
215 |
34 |
3,605 |
25,000 |
|
SB4206W1224 |
144 |
288 |
132 |
235 |
34 |
3,810 |
25,000 |
|
SB4206W1426 |
168 |
312 |
152 |
255 |
34 |
4,100 |
25,000 |
|
