Case IH Compact Farmall® 35A
Contact for Price
listing image
  • listing image
  • listing image
  • listing image
Call 905-562-4136

Item Details

ID: 13649640
Make: Case IH
Type: New
Year: 2017
Model: Compact Farmall® 35A
Horsepower, Maximum - Hp (kw): Same as advertised
Power Boost - Hp (kw): No boost
Engine Make: IHI Shibaura
Engine Model: N843T-F
Number Of Cylinders: 3
Fuel Tank Capacity - Gal (l): 7.4 (28)
Pto Speeds, Rpm: 540
Engine Bore, In (mm): 3.307 (84)
Engine Stroke, In (mm): 3.543 (90)
Front Tire Size, 2wd: No 2WD
Rated Engine Speed, Rpm: 2600
Advertised Engine Power, Rated, Hp (kw): 36.2 (27)

Item Description

 Compact Farmall® A Series
The compact Farmall® A series tractors are easy to operate and offer a comfortable operator environment allowing you to complete those every day chores without hassle.
The Power You Need To Get The Job Done

EngineEngine

These tractors feature an electronically controlled, indirect injection engine which features:
  • Faster throttle response and recovery under load
  • A quieter engine with less vibration, reducing operator fatigue
  • A greater torque rise, creating greater lugging power to accomplish more tasks and pull through tough situations, such as moving heavy loads or cutting thick grass
  • Glow plugs for easier starting
  • Quick & easy maintenance checkpoints

Standard TransmissionStandard Transmission

Standard 12x12 Mechanical transmission with shuttle:

  • 3 non-synchronized ranges
  • non-synchronized speeds
Optional TransmissionOptional Transmission

Optional 3-Range Hydrostatic transmission:
  • Simple 2 pedal operation
  • The Speed control lever allows the operator to easily manage a consistent speed while operating​
Easily Hook-up Loaders and Implements

Hitch
  • Safety Chain holder comes standard
  • Fixed lower links, single turnbuckle adjustment for leveling, and telescopic stabilizers
  • 3-Point Hitch capacity, 1345 lbs./610 kg. (24” behind ball ends, through full range)
  • Mechanical position control
  • Adjustable drop rate

Hydraulics

  • 8.2 GPM Hydraulic Flow
  • 1 or 2 remotes available from the factory
  • 1, 2, or 3 remotes available for dealer installation
  • Color-coded hydraulic levers and couplers for easy hook-up



 Compact Farmall® 35A
The compact Farmall 35A offers versatility in a well designed package.
