York BHQ 024 to 060 Affinity Packaged Heat Pump
Contact for Price
listing image
  • listing image
Call (705) 887-5559

Item Details

ID: 13239588
Make: York
Type: New
Year: 2014
Model: BHQ 024 to 060 Affinity Packaged Heat Pump
Capacity: 2 - 5 Tons
Efficiency: 14 SEER 8.0 HSPF
Phase : Single Phase or Three Phase Available
Configuration : Two Stage Compressor
Fan Motor: Variable-Speed Premium ECM Fan Motor
Capacity : 1.5 - 5 Tons
Efficiency Rating: 13 SEER
Energy Star®: Yes
Coil : MicroChannel Coil Technology
Emissions: LoNox Available

Item Description

York® light commercial packaged heat pumps include the high-end Affinity™ Series line and mid-brand Latitude™ and Sunline™ Series units up to 5 tons, plus high-capacity Predator™ rooftop models up to 12.5 tons.
Three Row Spike Drag Harrow

Three Row Spike Drag Harrow
Three Row Spike Drag Harrow


Certifications
  Features

  • All model sizes share a common compact cabinet in a single footprint for on-site flexibility.
  • Installation time and costs are reduced by easy power and control wiring. All units are factory-wired, charged with R-410A and tested prior to shipment.
  • Electric utility knockouts are provided on unit side and bottom for easy connections.
  • Convertible airflow design means no panel cutting is required and no accessory panel is necessary.
  • Condensate pan is non-corrosive, long-lasting and watertight.
  • Condensate drain is heavy-duty. A one-inch NPT copper connection is rigidly mounted for proper fit and a tight seal.
  • Durable finish made of powder-painted, galvanized steel meets 1,000-hour salt-spray test demands.
  • Full-perimeter base rails are easily removable, yet provide a solid unit foundation.
  • Top discharge allows warm air to be blown up away from the structure and landscaping.
  • Multi-pieces totally enclosed for maximum protection.
  • Units are engineered and built to be among the quietest models.
  • Compressor is internally protected against high pressure and temperature.
  • Grooved copper tubes and enhanced aluminum fin construction improve heat transfer.
  • Permanently lubricated condenser and evaporator fan motor bearings need no annual maintenance.
  • Secured service access ports are protected, externally mounted and reusable on both high and low lines.
  • Easy service access via a large single panel covering the electrical and gas controls.
